Interface
• 8*2.5G RJ45 port
• 1*10G RJ45 port
Port Standard
• IEEE802.3 (Ethernet)
• IEEE802.3u (Fast Ethernet)
• IEEE802.3ab (Gigabit Ethernet)
• IEEE 802.3bz (5G Ethernet)
• IEEE 802.3z (Gigabit Ethernet)
• IEEE 802.3ae (10 Gigabit Ethernet)
• IEEE802.3x (Flow Control)
Switching Capacity
• 60Gbps
Packet Forwarding Rate
• 44.64Mpps
Packet Buffer
• 8Mbit
MAC Address Table
• 4K
Jumbo Frame
• support
VLAN
• VLAN range 1-4094, maximum active VLAN is 31
Transmission Method
• Store and Forward
Surge Protection
• Surge protection: common mode 6KV, differential mode 2KV ;
• Electrostatic ESD: air 8KV, contact 6KV
Operating Temperature
• 0~40°C
Storage Temperature
• -40 °C to 70 °C
Operation Humidity
• 10%~90%，non condensing
Storage Humidity
• 5%~95%，non condensing
Power Supply
• AC 100-240V 50/60Hz
• DC 12V 1A
Mainboard Power Consumption
• 11.29W
Product Dimensions
• 190 x 100 x 28mm
Product Net Weight
• 0.49KG
Manager Access
• HTTP
Manager IP
• Static Address
• DHCP Client
User Management
• support
Firmware Management
• Firmware upgrade
Configuration Management
• Upload/Backup Configuration
Save
• support
Restart
• support
Factory Defaults
• support
