LED Indicators provide the easy-to-read status of the unit and utility power conditions.
Audible alarms provide notification of changing utility power and UPS power conditions
Cold-start capable
Boost Automatic Voltage Regulation (AVR) preserves battery life and maximizes runtime by correcting low voltages without discharging the battery.
Intelligent battery management maximizes battery performance, life, and reliability through intelligent, precision charging.
Safeguard your Home UPS from overloads, excessive mains voltages, short circuits, installation mishaps and battery damage due to low voltage situations.
Battery failure notification provides early-warning fault analysis on batteries enabling timely preventive maintenance
Battery and surge protected outlets
Outlets provide abundant runtime for network gateway equipment and other critical low-power devices, allowing for hours of internet access during a power outage
Output
Output power capacity: 300Watts / 500VA
Max Configurable Power (Watts): 300Watts / 500VA
Nominal Output Voltage: 230V
Output Frequency (not synced): 50/60 Hz +/-1 Hz
Topology: Line Interactive
Waveform type: Stepped approximation to a sinewave
Transfer Time: 6ms typical : 10ms maximum
Input
Nominal Input Voltage: 230V
Input frequency: 50/60 Hz +/- 5 Hz (auto sensing)
Input Connections: IEC-320 C14
Cord Length: 1.52meters
Number of Power Cords: 1
Batteries & Runtime
Battery type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Expected Battery Life (years): 3 - 5
Communications & Management
Control panel: LED Status display with On Line : On Battery
Audible Alarm: Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Physical
Maximum Height: 92mm, 9.25CM
Maximum Width: 160mm, 16.05CM
Maximum Depth: 305mm, 30.5CM
Net Weight: 3.9KG
Shipping weight: 4.2KG
Shipping Height: 237mm, 23.7CM
Shipping Width: 143mm, 14.3CM
Shipping Depth: 373mm, 37.3CM
SCC Codes: 1073130433829 8
Environmental
Operating Temperature: 0 - 40 °C
Operating Relative Humidity: 0 - 90 %
Operating Elevation: 0-1968.3meters
Audible noise at 1 meter from surface of unit: 40.0dBA
Conformance
Approvals: CE
Sustainable Offer Status
RoHS: Compliant
REACH: REACH: Contains No SVHCs
