The NETGEAR SOHO Ethernet Unmanaged Switches provide easy and affordable network connectivity
to small offices and home/offices. They are easy to use, reliable, and rugged with metal enclosures.
Power-over-Ethernet (PoE) support is also available for supplying both power and data across a single
CAT-5 ethernet cable to devices such as IP security cameras, VoIP phones, wireless access points, etc.
With these Plug-and-Play switches, you can quickly and easily expand your network connections to
multiple devices, with no configuration required. Available with 5 ports to 48 ports, these switches also
support energy saving technologies to help you save power and money.
Choice of Fast Ethernet and Gigabit Ethernet connectivity
Energy-efficient technology for power savings
Auto-MDI/MDIX eliminates the need for crossover cables
Non-blocking switching architecture for maximum throughput at wire speed
Auto-negotiation for automatic connection at the highest common speed between switch and an end device
Power-over-Ethernet (PoE) option available for powering IP Security Cameras, VoIP phones, wireless
access points, and other PD-powered devices
Fanless design for silent operation
Desktop, wall-mountable or rack-mountable (GS324, GS348)

Speed
Gigabit
Number of Ports
8
PoE Ports / Max Power Per Port
Ports 1-4 / 15.4W (802.3af)
PoE Max Power Supplied (All Ports)
53W
Connector Type
Metal
Switch Housing
Metal
LEDs
Power, Link/Activity (Left), Ports 1-4: PoE Power (Right)
Short cable power saving
Yes
Energy Efficient Ethernet Support (IEEE 802.3az)
Yes
Jumbo Frame Support
9,720 bytes
MAC Table Size
4K
Packet buffer size
192 KB
DC Power Adapter
48V / 1.25A
Max Power Consumption (Watts)
60.0W
Acoustic Noise Level @ 25° C (dBA)
0 dBA (Fanless)
Operating Temperature
0° to 40°C (32° to 104°F)
MTBF (@ 25° C)
2,244,211 hours
Electromagnetic compliance (A or B)
Class A
Form Factor
Desktop or wall-mountable
Dimensions (W x D x H)
158 x 101 x 29 mm (6.2 x 4.0 x 1.1 in)
Weight
0.46 kg (1.02 lb)
