Aruba Instant On Switch 8-Port Gigabit CL4 PoE 2p SFP 124W 1930
SKU: 8000000150134
Simplify Network Deployment and Management for Small Organizations
The HPE Networking Instant On Switch 1930 series features easy-to-use, out-of-the-box, plug-and-play deployment.
The series offers a complete portfolio of choices for increased small business flexibility. It consists of seven models including 8 G-, 24 G-, and 48 G-ports with and without class 4 PoE (i.e. PoE+).
The 24- and 48- port models include four SFP/SFP+ transceiver slots that support Gigabit or 10-Gigabit speeds for fiber connectivity.
The HPE Networking Instant On Switch 1930 series can be deployed using two management modes – Instant On cloud-management (access via mobile app and/or web portal) and the local web GUI.
Keep Your Business Protected with Integrated Security Features
The HPE Networking Instant On Switch 1930 series supports energy efficient Ethernet for lower power consumption and an enhanced feature set for more robust operation.
Enhanced security features such as IEEE 802.1x, and VLANs guard your network from unwanted or unauthorized access.
Automatic denial-of-service (DOS) monitors and protects the network against malicious attacks.
Management security restricts access to critical configuration commands, offers multiple privilege levels with password protection.
Deliver High Perfomance
The HPE Networking Instant On Switch 1930 series delivers advanced functionalities including customizable like VLANs, link aggregation, Spanning Tree Protocols, and IEEE 802.1X access control.
8-, 24-, and 48-port configurations with a choice of non-PoE and Class 4 PoE models provides deployment flexibility that fits all small business environment. Class4 PoE options allow to power devices like IP phones, surveillance cameras and access points, without the cost of additional cabling.
The 24- and 48-port models include 1 G/10 G SFP+ ports for reliable fiber connectivity and other connections across longer distances.
Differentiator
Ports: 8 Gigabit copper, Uplink ports: 2 SFP 1 GbE ports.
Power consumption
150.2W maximum, 11.7W idle
Input voltage
100 - 127 / 200 - 240 VAC
Port
s8 RJ-45 autosensing 10/100/1000 Class 4 PoE ports (IEEE 802.3 Type 10 BASE-T, IEEE 802.3u Type 100 BASETX, IEEE 802.3ab Type 1000 BASE-T)
Duplex: 10 BASE-T/100 BASETX: half or full; 1000 BASE-T: full only 2 SFP 1 GbE ports
Switching capacity
20 Gbps
Throughput
14.88 Mpps, maximum
Memory and processor
ARM Cortex-A9 @ 800 MHz
512 MB SDRAM, 256 MB flash
1.5 MB packet buffer
PoE capability
124 W Class 4
Operating temperature
32°F to 104°F (0°C to 40°C)
Management features
Instant On Portal, Web browser, SNMP Manager
Warranty
Limited lifetime warranty with 24X7 phone support for the first 90 days and chat support for the entire warranty duration.
Community support is available for the life of the product.
Weight
1.16 kg
Dimensions
4.39 x 25.4 x 25.4 cm
